Wire harness processing equipment is a collective term for machinery used in the production of wire harnesses. It is widely utilized across various industries in my country—including electronics, electric motors, and electrical appliances—for the processing of wire harnesses. The application of this equipment has significantly boosted production efficiency and product quality within the wire harness sector, while simultaneously reducing labor and material costs; consequently, it has become an indispensable "essential tool" for modern wire harness manufacturers.

Wire harness processing equipment encompasses a wide variety of types and serves diverse application scenarios. These include: fully automatic terminal crimping machines with heat-shrink tubing insertion capabilities, automotive wire harness processing centers, equipment for processing new-energy vehicle harnesses, fully automatic double-ended terminal crimping machines, fully automatic crimping and tin-dipping machines, fully automatic double-ended tin-dipping machines, fully automatic wire stripping machines, computerized automatic wire stripping machines, wire twisting machines, ribbon cable processing machines, and various other types of wire-end processing equipment.

Ruizhou Automation specializes in the R&D and manufacturing of high-precision wire harness processing equipment. The company offers a comprehensive range of machinery characterized by exceptional performance and quality. Furthermore, equipment can be customized to meet specific requirements, thereby enabling the company to effectively satisfy the diverse production needs of a broad user base—particularly those involving small-batch, multi-variety orders.

▲ Advantages and Features of the Fully Automatic Terminal Crimping Machine with Heat-Shrink Tubing Insertion

1. Data Integration: Processing data for the equipment can be seamlessly integrated with electrical design software—including domestic and international platforms such as Eplan, SEE Electrical, Lizhi, and Chengchuang. Alternatively, work orders can be imported via network transmission or USB drive transfer.

2. Wire Processing Range: The equipment is capable of processing wires with cross-sectional areas ranging from 0.3 mm² to 4.0 mm².

3. Simultaneous Processing Capability: The equipment can simultaneously accommodate up to 20 different types of terminals, 5 different types of heat-shrink tubing, and 40 different types of wires (varying in size and color), automatically selecting and feeding the appropriate materials for processing in real-time based on the specific work order.

▲ Advantages and Features of the Fully Automatic Double-Ended Terminal Crimping Machine

1. High-End Configuration: The fully automatic double-ended terminal crimping machine manufactured by Juchang Machinery features a premium configuration utilizing components from leading Japanese manufacturers: Mitsubishi servo motors; THK ball screws, linear guides, and linear modules; and SMC pneumatic cylinders, pressure regulators, and pressure switches. Furthermore, key auxiliary components include German FESTO solenoid valves, Japanese NSK bearings, and Japanese Keyence sensors. This high-spec configuration ensures performance capabilities that rival those of imported machinery. 2. High Precision: During processing and cutting, the insulation cut is clean and neat, with no scratching of the copper wire cores and no severed copper strands. The stripping tolerance can be controlled within 0.05mm, and the crimping height tolerance within 0.01mm; the equipment's processing precision meets or exceeds the IPC/WHMA-A-620 Class 3 standard.

3. High Efficiency: Capable of reaching a maximum processing speed of 3,000 wires per hour; actual processing capacity varies depending on the wire type, length, stripping length, and terminal crimping time.

4. Ease of Operation: Juchang Machinery’s fully automatic double-head terminal machine is powered by servo motors, requiring no manual intervention during the production process. When switching wires, terminals, or molds, there is no need to manually adjust the crimping height; digital settings can be configured via the screen in just one minute. The operation is simple, production efficiency is high, and the machine features automatic detection of terminal crimping quality.

▲ Advantages and Features of Wire Harness Processing Equipment: Fully Automatic Wire Stripping Machines

1. Fully Automatic Computerized Cutting and Stripping Machine: Features full digital intelligent control, allowing for simple configuration of every function. It can store up to 100 sets of processing data and intelligently executes fixed-length cutting and simultaneous stripping in a single operation.

2. Specialized Application: Designed specifically for the fully automatic fixed-length feeding, double-end stripping, and cutting of large-cross-section cables—such as those used in EV charging piles, power distribution cabinets, and high-voltage power lines.

3. High-Precision Mechanism: The cutter head assembly utilizes a dual-servo motor and dual-ball screw drive system to ensure exceptional processing precision.

4. Core Protection: Juchang Machinery’s fully automatic wire stripping machines employ a belt-driven wire feeding system to ensure that the wire cores remain undamaged during processing.

5. User-Friendly Interface: Features fully digital intelligent settings and touch-screen operation, making it convenient and simple to use.

Juchang Machinery’s wire harness processing equipment is characterized by its high precision, advanced configuration, and exceptional flexibility. It effectively resolves complex challenges that traditional wire harness processing methods struggle to overcome, thereby contributing to the thriving development of the secondary wire harness industry.
