Model
8030Z Mid-span stripping
Display method
7-inch true color touchscreen
Function
Automatic cutting and stripping of wires and cables, with intermediate stripping function.
Wire type
Wires, cables, PVC, etc.
stripping range
1-30 square
Cutting length
1mm-99999.99mm
Cutting tolerance
0.002*L within（L=Cutting length）
Peeling length
Full front detachment: 1-200mm; Partial front detachment: 1-500mm
Fully detached rear end: 1-80mm; partially detached rear end: 1-500mm (customizable).
Mid-span stripping
Multiple segments with intermediate peeling, arbitrary intervals, arbitrary peeling lengths, maximum 32 segments.
Multiple segments with intermediate peeling, each segment with the same interval and the same peeling length, unlimited number of segments.
Allowed through the maximum diameter
Φ16
Tool materials
High-quality imported high-speed steel
Productivity (times/hour)
2000 PCS/H (Depending on the length and size of the line)
driving method
Silent hybrid stepper motor, servo tool holder
Cable delivery method
The cable is fed by a belt and has no dents or scratches.
Remark
Special cables can be customized; sample cables must be sent for testing.
